HPE Networking · Managed Switches
S4A30A – HPE Networking Instant On Switch 24p Gigabit 4p SFP+ 1940
Twenty-four port Layer 2+ gigabit switch with four 1/10G SFP+ uplinks — rack density without PoE cost.
PricingContact for Best Price
- Ports
- 24× GbE RJ45 (ports 1–24)
- Uplinks
- 4× 1/10G SFP+ (ports 25–28)
- PoE
- None
- Switching capacity
- 128 Gbps
- Throughput
- 95 Mpps
- Mounting
- 1U rack, 2-post kit included
- Ready Stock
- PAN India Supply
- Same Day Dispatch*
- GST Billing
- BOQ Assistance
*Same-day dispatch applies to in-stock items ordered before cut-off from the Delhi NCR warehouse.
Key Features
What the S4A30A is built to do
Technical Specifications
S4A30A specifications
Specifications as published for this model. Confirm project-critical values against the datasheet before ordering.
| Ports | |
|---|---|
| Access ports | 24× RJ-45 autosensing 10/100/1000BASE-T (ports 1–24) |
| Uplink | 4× SFP+ 1/10GbE ports (ports 25–28) |
| Standards | IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T |
| Duplex | 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only |
| Console port | 1× USB-C console port |
| PoE | |
|---|---|
| PoE output | None — this model does not supply PoE |
| PoE alternative | See the S4A31A for a 24-port model with Class 4 PoE at 240 W |
| Performance | |
|---|---|
| Switching capacity | 128 Gbps |
| Throughput | 95 Mpps @ 64-byte packets |
| Latency (100 Mb, LIFO) | < 6.5 µs |
| Latency (1000 Mb, LIFO) | < 2.7 µs |
| Latency (10000 Mb, LIFO) | < 0.75 µs |
| MTBF | 178 years |
| Scale | |
|---|---|
| MAC address table | 16,000 entries |
| Maximum VLANs | 256 (VLAN IDs 1–4093) |
| IPv4 host table (ARP) | 509 entries |
| IPv4 unicast static routes | 32 |
| Routing table | 32 IPv4 static entries |
| IGMP groups | 1K |
| IPv4/MAC ACL entries (ingress) | 100 |
| Maximum ACEs | 2048 |
| Jumbo frames | Up to 9216 bytes |
| IPv4/MAC ACL entries (egress) | 512 |
| Link aggregation groups | 16 (4 members per group) |
| Processor and Memory | |
|---|---|
| Processor | ARM Cortex-A9 @ 1.25 GHz |
| SDRAM | 1 GB |
| Flash | 512 MB |
| Packet buffer | 2 MB |
| Physical | |
|---|---|
| Dimensions (D × W × H) | 12.09 × 17.48 × 1.73 in (30.70 × 44.40 × 4.40 cm) |
| Weight | 6.70 lb (3.04 kg) |
| Fans | 1 fixed fan, non field-replaceable |
| Primary airflow | Left to right |
| Acoustics | Sound power LWAd = 3.4 Bel; bystander sound pressure LpAm = 20 dB |
| Mounting | EIA-standard 19 in. rack or cabinet (2-post kit included); table-top; rack; wall; under-table |
| Electrical | |
|---|---|
| Power supply type | Internal power supply |
| AC voltage | 100–127 VAC / 200–240 VAC |
| Frequency | 50 Hz / 60 Hz |
| Current | 0.45 / 0.33 A |
| Power consumption (100% traffic) | 100–127 V: 25.3 W; 200–220 V: 25.9 W |
| Power consumption (idle) | 100–127 V: 11.8 W; 200–220 V: 12.1 W |
| Heat dissipation (100% traffic) | 100–127 V: 86.4 BTU/hr, 91.2 kJ/hr; 200–220 V: 88.2 BTU/hr, 93.1 kJ/hr |
| Environment | |
|---|---|
| Operating temperature | 32 °F to 104 °F (0 °C to 40 °C) |
| Storage temperature | −40 °F to 158 °F (−40 °C to 70 °C) |
| Operating humidity | 15% to 95% @ 104 °F (40 °C), non-condensing |
| Storage humidity | 15% to 95% @ 140 °F (60 °C), non-condensing |
| Altitude | Up to 10,000 ft (3 km) |
| Layer 2 Switching | |
|---|---|
| Spanning tree | 802.1D STP, 802.1w RSTP, 802.1s MSTP (local web only, up to 8 instances), BPDU filtering, loop protection |
| Flow control | IEEE 802.3x, symmetric and asymmetric |
| Link aggregation | LACP or static, up to 16 LAGs with up to 8 ports each depending on model |
| Multicast | IGMP v1, v2, v3 snooping |
| Discovery | LLDP and LLDP-MED |
| Monitoring | Port mirroring and RSPAN |
| Auto VLAN | Auto-detects access points and cameras into pre-defined VLANs |
| Auto recovery | Returns a port or service online after an error condition |
| Layer 3 Routing | |
|---|---|
| Static IPv4 routing | Up to 32 IPv4 routing interfaces and 32 IPv4 static routes |
| Address assignment | Manual or DHCP, per port or per VLAN |
| ARP | Dynamic and manual entries |
| IPv6 | IPv6 Host mode |
| Quality of Service | |
|---|---|
| Classification | CoS by IEEE 802.1p or DSCP; Global Trust Mode |
| Queue scheduling | Weighted round robin (WRR) or strict priority (SP) |
| Traffic shaping | Per-port egress bandwidth limit |
| Rate limiting | Broadcast, multicast and unicast thresholds with port shutdown or SNMP trap |
| Auto-voice VLAN | Detects SIP, H.323 and SCCP or by OUI |
| Security | |
|---|---|
| Hardware root of trust | TPM 2.0 |
| Port authentication | IEEE 802.1X |
| AAA | RADIUS, TACACS+ or local database |
| RADIUS servers | Up to 2, with RADIUS-assigned dynamic VLANs and accounting |
| DoS protection | Automatic denial-of-service protection |
| Access control | ACLs with MAC and IP filtering; time-based ACLs |
| Management | |
|---|---|
| Options | Instant On Cloud Portal; Mobile App; Web Browser; SNMP Manager; DOCs (Telnet, SSH); Console Port (USB-C) |
| Local web sessions | Up to 5 HTTP / HTTPS |
| Devices per site | Up to 125 |
| Scheduling | Up to 3 global schedules for ACLs, port shutdown or PoE |
| Diagnostics | Event logging and alerts, locator LED, port mirroring |
| Supported Transceivers (1G SFP) | |
|---|---|
| S0G20A | Instant On 1G LX SFP LC 10 km SMF transceiver |
| R9D16A | Instant On 1G SFP LC SX 500 m OM2 MMF transceiver |
| R9D17A / R9D17B | Instant On 1G SFP RJ45 100 m Cat5e transceiver |
| Supported Transceivers (10G SFP+) | |
|---|---|
| S0G21A | Instant On 10G LR SFP+ LC 10 km SMF transceiver |
| S0G18A | Instant On 10GBASE-T RJ45 30 m Cat6a transceiver |
| R9D18A | Instant On 10G SFP+ LC SR 300 m OM3 MMF transceiver |
| R9D19A / R9D20A | Instant On 10G SFP+ to SFP+ 1 m / 3 m direct attach copper cable |
| Compliance & Warranty | |
|---|---|
| Safety | EN/IEC 62368-1 2nd & 3rd Ed.; UL 62368-1 3rd Ed.; CAN/CSA C22.2 No. 62368-1 3rd Ed.; EN/IEC 60825-1:2014 Class 1 |
| Emissions | EN 55032:2015/CISPR 32 Class A; FCC CFR 47 Part 15:2018 Class A; ICES-003 Class A; VCCI-32 Class A; CNS 13438 Class A; KS C 9832 Class A; AS/NZS CISPR 32 Class A |
| Immunity | BS/EN 55035, CISPR 35, KS C 9835; IEC 61000-4-2/-3/-4/-5/-6/-8/-11 |
| Warranty | HPE Networking Instant On limited lifetime; chat support for the life of the product |
Specifications sourced from the official HPE Networking catalogue. Where official pages disagree on a value, it is marked and confirmed during quotation.
Overview
About the S4A30A
The HPE Networking Instant On Switch 24p Gigabit 4p SFP+ 1940 (S4A30A) is a 24-port smart-managed Layer 2+ gigabit switch with four dedicated SFP+ uplink ports running at 1G or 10G, and no Power over Ethernet.
The four 10G uplinks are the reason to choose the 1940 generation over the 1840 at this port count: where the 1840's 24-port models cap their uplinks at 1G SFP, this one aggregates a full floor of gigabit access into 10-gigabit fibre, and switching capacity rises accordingly to 128 Gbps with 95 Mpps forwarding.
It draws 0.45 A and 25.3 W at full traffic, the lowest of any 24- or 48-port model in the series, and runs a single fan rated at 3.4 Bel. Where the access points and cameras are powered elsewhere, dropping the PoE stage removes both cost and heat.
Applications
Where the S4A30A is deployed
Downloads
S4A30A documents
Datasheets and manuals are shared without sign-up. Documents not yet hosted online are sent on request within working hours.
- HPE Networking Instant On Switch Series 1940 QuickSpecs (PDF)Download
Related Products
Pairs with the S4A30A
Edge PoE switches below it, SFP+ modules in its uplinks, and sibling models for smaller or larger sites.
- PoE Switches
Managed Switches- 48× GbE
- 4× 1/10G SFP+
- 176 Gbps
Managed Switches- 24× GbE
- 4× SFP
- 56 Gbps
Before You Enquire
Frequently asked questions
Does the S4A30A supply PoE?
No. All 24 ports are standard gigabit copper with no power. For a 24-port 1940 with PoE, the S4A31A provides Class 4 PoE across all 24 ports within a 240 W budget, and the S4A32A adds four 2.5G Class 6 ports within 370 W.
Compare the S4A31AWhat speed do the SFP+ ports run at?
Each of the four SFP+ ports runs at 1G or 10G. They are dedicated uplinks, additional to the 24 copper ports, so using fibre does not reduce the number of available access ports.
Browse SFP modulesHow does the S4A30A compare with the 1840 S5E28A?
Both are 24-port non-PoE switches with four SFP uplinks. The 1940 runs those uplinks at 10G against 1G on the 1840, lifts switching capacity from 56 Gbps to 128 Gbps and throughput from 41.66 Mpps to 95 Mpps, and adds IPv4 static routing, 256 VLANs against 64, and a USB-C console port.
Compare the S5E28AHow noisy is the S4A30A?
HPE rates it at 3.4 Bel declared sound power and 20 dB mean bystander sound pressure, with one fixed non field-replaceable fan and left-to-right airflow.
What is the price of the HPE S4A30A in India?
Pricing is quotation-based with dealer slabs for registered partners. Name the S4A30A and quantity in a quote request and you receive priced options with confirmed availability within 24 working hours.
