Lysora · PoE Switches

LCS-8GS-P

8-Port Cloud Managed PoE Switch

PricingContact for Best Price
Ports
8× GbE PoE/PoE+
Uplink
1× GbE combo + 1× SFP
PoE budget
120 W
Management
Web / Cloud / App
Camera rating
40 (200 W H.265)
Warranty
3 years (manufacturer)
Request QuoteUpload BOQWhatsApp
  • Ready Stock
  • PAN India Supply
  • Same Day Dispatch*
  • GST Billing
  • BOQ Assistance

*Same-day dispatch applies to in-stock items ordered before cut-off from the Delhi NCR warehouse.

Key Features

What the LCS-8GS-P is built to do

120 W PoE/PoE+ budget

Eight powered ports with real PoE+ headroom.

Cloud + app managed

Remote monitoring of unattended sites.

PoE watchdog

Auto power-cycles hung cameras.

SFP uplink

Fiber option for longer backhauls.

Compact fanless case

202×108×28 mm, 0.55 kg — silent shelf unit.

NDAA compliant

FCC and IC certified.

Technical Specifications

LCS-8GS-P specifications

Specifications as published for this model. Confirm project-critical values against the datasheet before ordering.

Interfaces specifications
Interfaces
PoE ports8× 10/100/1000BASE-T PoE/PoE+
Uplink1× GbE combo + 1× GbE SFP
PoE specifications
PoE
Total budget120 W
Camera capacity40 (200 W H.265) / 20 (400 W H.265)
Performance specifications
Performance
Switching capacity20 Gbps
Forwarding rate14.8 Mpps
Buffer / Flash1.5 Mbit / 4 MB
Physical & Environmental specifications
Physical & Environmental
Dimensions202 × 108 × 28 mm
Weight0.55 kg
Power54 V DC adapter
Consumption130 W max
Operating temperature0 °C to +40 °C
MTBF200,000 hours
Surge / ESD±6 kV / 8 kV air, 6 kV contact
Compliance & Warranty specifications
Compliance & Warranty
CertificationsFCC, IC; NDAA compliant
Warranty3 years

Specifications sourced from the official Lysora catalogue. Where official pages disagree on a value, it is marked and confirmed during quotation.

Overview

About the LCS-8GS-P

The Lysora LCS-8GS-P is an 8-port cloud managed PoE switch with a 120 W PoE/PoE+ budget, a gigabit combo uplink, and an SFP slot. Lysora rates it for 40 cameras at the 200 W H.265 profile.

Management runs over web, Lysora Cloud, or the app, with the CCTV-focused feature set of the LCS line: camera detection, PoE watchdog, and online upgrade.

It is the step-up small-site unit — eight powered drops in a compact fanless case for shops, offices, and camera strings that outgrow four ports.

Applications

Where the LCS-8GS-P is deployed

Shop & office CCTV

Eight-camera strings with cloud oversight.

AP + phone edge

Power wireless and voice from one shelf unit.

Retail chains

Standardized per-store PoE, managed centrally.

Small office edge

The default 8-drop powered access switch.

Downloads

LCS-8GS-P documents

Datasheets and manuals are shared without sign-up. Documents not yet hosted online are sent on request within working hours.

Related Products

Pairs with the LCS-8GS-P

Edge PoE switches below it, SFP+ modules in its uplinks, and sibling models for smaller or larger sites.

Why Buy From Lizora Infotech

A supply partner, not just a price list

Ready Stock Availability

Fast-moving SKUs held in the Delhi NCR warehouse, with availability confirmed on every quotation.

PAN India Supply Network

Surface and air cargo delivery to every state, with GST invoicing and e-way bills handled end to end.

BOQ & Solution Consultation

Bill-of-quantities reviewed line by line, with alternatives suggested for out-of-stock or discontinued items.

Technical Pre-Sales Consulting

Switch sizing, PoE budgets, VLAN design, and GPON planning reviewed by our technical team before you commit.

Dedicated B2B Sales Support

A named point of contact for quotes, stock checks, and RMA — not a ticket queue.

Request Dealer Pricing

Related Resources

Guides that cover the LCS-8GS-P

Selection and background reading from our technical team.

  • Buying Guides

    Industrial Switch Buying Guide

    When a commercial switch is the wrong choice, and how to specify an industrial one: temperature rating, mounting, DC input, ingress protection, and surge tolerance.

Before You Enquire

Frequently asked questions

What is the difference between the LCS-8GS-P and LS2-8GT2SFP-P?

Both are 8-port Lysora PoE switches. The LCS-8GS-P is a cloud managed smart switch (120 W) aimed at CCTV and small sites; the LS2-8GT2SFP-P is a full Layer 2 managed switch (125 W) with VLANs to 4094 and two SFP slots for network-integrated deployments.

See the L2 managed model

Can I manage the LCS-8GS-P remotely?

Yes. It supports Lysora Cloud and app management alongside the local web interface, so multi-site operators can monitor ports, PoE status, and cameras across locations without visiting each site.

What is the price of the LCS-8GS-P in India?

Pricing is quotation-based with dealer slabs for registered partners. Send a quote request naming the LCS-8GS-P and quantity, and you receive priced options with stock confirmation within 24 working hours.

Request pricing
