Lysora · Managed Switches

LS2-24GT4SFP-P

24-Port Layer 2 Managed PoE Switch

PricingContact for Best Price
Ports
24× 10/100/1000BASE-T PoE/PoE+
Uplinks
4× 1GE SFP
PoE budget
370 W
Layer
Layer 2 managed
Camera rating
120 (200 W H.265)
Warranty
3 years (manufacturer)
Request QuoteUpload BOQWhatsApp
  • Ready Stock
  • PAN India Supply
  • Same Day Dispatch*
  • GST Billing
  • BOQ Assistance

*Same-day dispatch applies to in-stock items ordered before cut-off from the Delhi NCR warehouse.

Key Features

What the LS2-24GT4SFP-P is built to do

370 W PoE/PoE+ budget

Full PoE+ across 24 ports for cameras, APs, and phones.

Rated for 120 cameras

Official capacity at the 200 W H.265 profile; 60 at 400 W.

4× SFP fiber ports

Uplink aggregation to the core over fiber.

L2 management

VLANs up to 4094 with web and cloud management.

16 MB flash, 8K MAC table

56 Gbps capacity at 41.66 Mpps forwarding.

NDAA compliant

FCC, IC, cTUVus certifications; NDAA compliance flagged by Lysora.

Technical Specifications

LS2-24GT4SFP-P specifications

Specifications as published for this model. Confirm project-critical values against the datasheet before ordering.

Interfaces specifications
Interfaces
RJ45 ports24× 10/100/1000BASE-T, PoE/PoE+
SFP slots4× 1GE SFP
PoE specifications
PoE
StandardPoE/PoE+
Total budget370 W
Camera capacity120 (200 W H.265) / 60 (400 W H.265)
Switching Performance specifications
Switching Performance
Switching capacity56 Gbps
Forwarding rate41.66 Mpps
MAC address table8,000 entries
Packet buffer4.1 Mbit
Flash memory16 MB
L2 Features specifications
L2 Features
VLANUp to 4094
ManagementWeb; cloud management support
Physical & Environmental specifications
Physical & Environmental
Dimensions440 × 215 × 44 mm (1U)
Weight3 kg
Power supply100–240 V AC
Consumption443 W at full PoE load
Operating temperature0 °C to +50 °C
MTBF400,000 hours
Compliance & Warranty specifications
Compliance & Warranty
CertificationsFCC, IC, cTUVus; NDAA compliant
Warranty3 years

Specifications sourced from the official Lysora catalogue. Where official pages disagree on a value, it is marked and confirmed during quotation.

Overview

About the LS2-24GT4SFP-P

The Lysora LS2-24GT4SFP-P is a 24-port gigabit Layer 2 managed PoE switch with a 370 W PoE/PoE+ budget and four SFP ports. Lysora rates it for 120 cameras at a 200 W H.265 profile and 60 at 400 W, making it the standard closet switch for surveillance-heavy sites.

L2 management covers VLANs up to 4094 with web and cloud control, so camera, voice, and data traffic stay segmented on shared infrastructure.

It aggregates to the core over its SFP ports and scales up to the 48-port LS2-48GT4SFP-P where device counts grow.

Applications

Where the LS2-24GT4SFP-P is deployed

Surveillance closets

120-camera rating covers most single-building CCTV BOQs.

AP distribution

PoE+ for Wi-Fi 6/7 access points across a floor.

Office access layer

Phones, desktops, and cameras on segmented VLANs.

Hospitality floors

Room APs, corridor cameras, and phones per floor.

Downloads

LS2-24GT4SFP-P documents

Datasheets and manuals are shared without sign-up. Documents not yet hosted online are sent on request within working hours.

Related Products

Pairs with the LS2-24GT4SFP-P

Edge PoE switches below it, SFP+ modules in its uplinks, and sibling models for smaller or larger sites.

Why Buy From Lizora Infotech

A supply partner, not just a price list

Ready Stock Availability

Fast-moving SKUs held in the Delhi NCR warehouse, with availability confirmed on every quotation.

PAN India Supply Network

Surface and air cargo delivery to every state, with GST invoicing and e-way bills handled end to end.

BOQ & Solution Consultation

Bill-of-quantities reviewed line by line, with alternatives suggested for out-of-stock or discontinued items.

Technical Pre-Sales Consulting

Switch sizing, PoE budgets, VLAN design, and GPON planning reviewed by our technical team before you commit.

Dedicated B2B Sales Support

A named point of contact for quotes, stock checks, and RMA — not a ticket queue.

Request Dealer Pricing

Related Resources

Guides that cover the LS2-24GT4SFP-P

Selection and background reading from our technical team.

  • Buying Guides

    How to Choose the Right Managed Switch

    A six-step method for sizing a managed switch — port count, PoE budget, uplinks, switching layer, environment, and management — before the BOQ goes out for pricing.

  • Buying Guides

    Network Switch Selection Guide

    A decision tree across the whole switch range — unmanaged, managed, PoE, multi-gig, Layer 3, and industrial — mapping site type to the right class of switch.

Before You Enquire

Frequently asked questions

How many cameras can the LS2-24GT4SFP-P power?

Lysora rates it for 120 cameras on a 200 W H.265 profile and 60 on a 400 W profile, within its 370 W PoE/PoE+ budget. Real counts depend on per-camera draw including IR at night — share your camera model for confirmed sizing.

Request a sizing quote

What uplinks does the LS2-24GT4SFP-P have?

Four 1GE SFP ports. For 10G aggregation in the same Lysora managed family, the LS2P-8MG2XS-P provides two 10GE SFP+ slots, and the LS3-24SFP/8GT4XS offers four SFP+ ports at the core.

See the L3 core switch

What is the price of the LS2-24GT4SFP-P in India?

Pricing is quotation-based with dealer slabs for registered partners. Send a quote request naming the LS2-24GT4SFP-P and quantity, and you receive priced options with stock confirmation within 24 working hours.

Request pricing
